Grandstream GWN7664E AX6000 Wi-Fi 6 Access Point
The Grandstream GWN7664E is a high-performance indoor Wi-Fi 6 access point designed for business environments that require fast wireless connectivity, reliable coverage and support for multiple connected devices. With AX6000-class performance, dual-band 4×4:4 MU-MIMO and OFDMA technology, it is suitable for offices, schools, hotels, commercial buildings and multi-floor deployments.
Key Features
-
AX6000-class Wi-Fi 6: Up to 6 Gbps aggregate theoretical wireless throughput.
-
Dual-band 4×4:4 MU-MIMO: Supports simultaneous communication with compatible devices on both 2.4 GHz and 5 GHz bands.
-
OFDMA technology: Helps improve wireless efficiency in networks with multiple connected clients.
-
Dual 2.5 Gigabit Ethernet ports: Provides high-speed wired connectivity and greater network capacity.
-
PoE+ powered: Supports IEEE 802.3at Power over Ethernet. A separate power adapter is not included with the standard package.
-
High client capacity: Supports up to 512 concurrent Wi-Fi clients.
-
Wide coverage: Manufacturer-rated coverage of up to 175 metres, depending on environmental conditions.
-
Flexible network management: Supports local embedded management, Grandstream GDMS Networking cloud management and GWN Manager.
-
Advanced security: Includes WPA3 support, secure boot and digital-signature-based security protections.
-
Business networking features: Supports QoS, VLANs, mesh networking and captive portals.
Technical Specifications
| Specification | Details |
|---|---|
| Brand | Grandstream |
| Model | GWN7664E |
| Product type | Indoor wireless access point |
| Wi-Fi standard | Wi-Fi 6 (IEEE 802.11ax) |
| Wireless class | AX6000 |
| Frequency bands | 2.4 GHz and 5 GHz |
| Antennas | 8 internal antennas |
| MU-MIMO | 4×4:4 on both bands |
| Maximum aggregate wireless throughput | Up to 6 Gbps |
| Ethernet ports | 2 × 2.5 Gigabit Ethernet |
| Power input | PoE+ (IEEE 802.3at) |
| Maximum power consumption | 21 W |
| Maximum concurrent clients | 512 |
| Maximum rated coverage | Up to 175 metres |
| Security | WPA/WPA2, WPA3 and secure boot |
| Management | Embedded controller, GDMS Networking, GWN Manager |
| Mounting | Indoor wall or ceiling mounting |
| Operating temperature | 0°C to 50°C |
Package Contents
-
Grandstream GWN7664E Wi-Fi 6 access point
-
Mounting kits
-
Quick Start Guide
Power adapter is not included. A compatible PoE+ switch or injector is required unless an appropriate separate power solution is purchased.
Recommended Applications
-
Business and enterprise wireless networks
-
Schools, colleges and training centres
-
Hotels and hospitality venues
-
Multi-floor offices and commercial buildings
-
High-density wireless environments
-
Voice, video conferencing and other bandwidth-intensive business applications
Actual wireless speeds and coverage depend on client devices, network configuration, interference, building materials and local radio regulations.
